Quick Details

  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: Kaiyuan
  • Model Number: KYC
  • Theory: Centrifugal Pump
  • Structure: Single-stage single-suction, single-stage double-suction, multistages
  • Usage: Water
  • Power: Diesel Engine Driven
  • Standard or Nonstandard: Standard
  • Fuel: Diesel
  • Pressure: 0.3-2.5Mpa, 0.2~1.8MPa
  • Application: Fire Pump, Irrigation Pump, Agricultural Water Pump, Fire-fighting Pump, Irrigation, Agricultural Water Pump
  • Capacity: 5~200L/s
  • Medium temperature: ≤85℃
  • National standard: GB6245-2006
  • Sub-categories: XBC-IS, XBC-S and XBC-D
  • Provide power: X6135, 12v135, 4102, 4105, 61 02, 4100, 495 etc.
  • Components: diesel tank, radiation water tank, blower, control panel
  • Description: Agriculture Pump Diesel Fuel Agricultural Pump

Packaging & Delivery

Packaging Details Wooden Carton or following customers' requirements.
Delivery Time Generally with in 20 days, depends on the quantity of the order

Specifications

XBC China Supplier Diesel Engine Pump Fire Pump
1) Agricultural Water Pump
2) Diesel Engine Water Pump
3) ISO9001


Product Description

KYC China Supplier Agriculture Pump Diesel Fuel Agricultural Pump

>>> Product Overview



As a fire-fighting latest equipment, XBC diesel engine fire-fighting pump group series are developed successfully, strictly complying with national standard GB6245-2006, The Performance Requirement and Testing Method of Fire Fighting Pumps and with NEPA20, Installation of Centrifugal Fire-fighting Pumps.



Classified by coupled pump head types (single stage single suction type, single stage double suction type, multi-section multistage type), this equipment can fall into three sub-categories: XBC-IS, XBC-S and XBC-D. The equipment is widely used in many occasions.



This equipment can use high quality diesel engines from domestic market or foreign countries, so it is the fire protection equipment with advantages as follows, stable start, high capacity, compact structure, easy maintenance, high automation and advanced and dependable performance.





>>>Structure And Functions



X6135, 12v135, 4102, 4105, 61 02, 4100, 495 etc diesel engine series provide power for our pumps. Our fire-fighting pumps are flexible coupled with these diesel engines (clutches are available). Besides, diesel tank, radiation water tank, blower, control panel (for the automatic unit) etc can be provided as components.



Being the auto-control unit, a separate diesel engine auto-control panel (programmable) carries out the system’s automatic start, run, auto-switch (the electric motor pump unit is switched to the diesel engine pump or the diesel engine pump unit to another diesel pump unit), auto-protection (warning and stop protection for the diesel engine’s over-speed, lower oil pressure, high water temperature, three-time start failures, low voltage of accumulator warning etc.) and also can be connected to user’s fire-fighting center or the fire auto-warning device with the purpose of remote monitoring.



In order to keep the unit working normally below 5ºC, it can be fitted with an AC 220v water cooling system.



The diesel engine fire-fighting pump group can be formed with electric motor pumps and jockey pumps as an automatic fire-fighting water supply system (see tabel1). For more details, please see our document "Diesel Engine Control System". The system also can be connected to the fire-fighting center.



There are two ways of inletting the water: manual water adding and water self-priming. the former is preferred in accordance with fire-fighting protection standard. Automatic vacuum water self-priming devices can be provided only when customers request. In this case, the dimension of the diesel engine pump unit is changed.





>>> Product Show









KYC China Supplier Agriculture Pump Diesel Fuel Agricultural Pump





>>> Parameters

  • Capacity: 5~200L/s
  • Pressure: 0.2~1.8MPa
  • Medium temperature: ≤85 ºC



>>> Model Meaning

  • XB: Engineering-oriented Application
  • C: Diesel-driven Engine



>>> Part Of Model Parameters



ModelRated Speed
(r/min)

Rated

Capacity

(L/s)

Rated

Pressure
(MPa)

Eff.
(%)
NPSH
(m)
Shaft Power
(kW)

Diesel Engine

Power
(kW)

Inlet/Outlet
Diameter
(mm)
Weight
(kg)
3/102000100.3712.55.57.5100/6591
3/202000200.37139.513.8100/6591
3/302000300.3693.816.820.6125/100129
3/402000400.3774.818.523.2125/100129
4/102000100.4712.57.413.8100/6591
4/202000200.477311.215.3125/100129
4/302000300.4743.618.226.5125/100145
5/102000100.5654.28.713.8100/65120
5/202000200.5654.519.926.5100/65120
5/302000300.5744.525.735.3125/100145
5/402000400.5744.932.835.5125/100145
5/501500500.5752.836.358150/125212
5/10015001000.5813.867.2105200/150245
5/11015001100.5814.568.4105200/150245
6/102000100.6652.511.515.3100/65120
6/202000200.674319.726.5125/100145
6/302000300.6743.629.740.4125/100145
4/301500300.475.54.115.620.6125475
6/301500300.675.54.123.431.6125555
8/301500300.875.54.131.234.3125640
10/30150030175.54.13958125726
12/301500301.275.54.146.875125840
14/301500301.475.54.154.675125923
16/301500301.675.54.162.4751251008
18/301500301.875.54.170.21101251093
6/401500400.6773.932.858150490
9/401500400.9773.949.375150575
12/401500401.2773.965.775150660
15/141500401.5773.982.1110150745
18/401500401.8773.998.5160150830
8/801500800.8774.785.2110200667
12/801500801.2774.7127.7160200787
16/801500801.6774.7170.3220200907
20/801500802774.7212.32792001027
25/801500802.5774.7255.52792001147
18/12515001251.8794.9229.23382501750



KYC China Supplier Agriculture Pump Diesel Fuel Agricultural Pump
